58E

Samsung

Premium Cell

58E

Samsung

Premium Cell

Overview

Manufacturer: Samsung
Model: 58E
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2024

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 74 g
Volume: 26.45 cm³
Height: 71 mm
Diameter: 21.78 mm

Chemistry

Positive Electrode Material: Ni-based
Negative Electrode Material: Graphite/Si additive

Electrical

Nominal Energy Capacity: 19.998 Wh
Nominal Charge Capacity: 5.5 Ah
Gravimetric Energy Density: 270 Wh/kg
Volumetric Energy Density: 756 Wh/L
Gravimetric Power Density: 540 W/kg
Volumetric Power Density: 1512 W/L
Max Continuous Charge: 5.5 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Subscribe to Voltt Premium to run simulations using this cell

Overview

Manufacturer: Samsung
Model: 58E
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2024

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 74 g
Volume: 26.45 cm³
Height: 71 mm
Diameter: 21.78 mm

Chemistry

Positive Electrode Material: Ni-based
Negative Electrode Material: Graphite/Si additive

Electrical

Nominal Energy Capacity: 19.998 Wh
Nominal Charge Capacity: 5.5 Ah
Gravimetric Energy Density: 270 Wh/kg
Volumetric Energy Density: 756 Wh/L
Gravimetric Power Density: 540 W/kg
Volumetric Power Density: 1512 W/L
Max Continuous Charge: 5.5 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Subscribe to Voltt Premium to run simulations using this cell

Max Continuous Charge (C-rate)

1 C

Max Continuous Discharge

11 A

Max Continuous Discharge (C-rate)

2 C

Voltage

Nominal Voltage

3.636 V

Max Voltage

4.2 V

Min Voltage

2.5 V

Max Continuous Charge (C-rate)

1 C

Max Continuous Discharge

11 A

Max Continuous Discharge (C-rate)

2 C

Voltage

Nominal Voltage

3.636 V

Max Voltage

4.2 V

Min Voltage

2.5 V
