Cell Library

Name: Samsung 50G
Brand: Samsung

Create a Free Account or Login

50G

Samsung

Coming Soon

50G

Samsung

Coming Soon

Overview

Manufacturer: Samsung
Model: INR21700-50G
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2018

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 69.5 g
Volume: 24.53 cm³
Height: 70.15 mm
Diameter: 21.1 mm

Chemistry

Positive Electrode Material: Ni-based (high Ni)
Negative Electrode Material: Graphite/Si additive

Electrical

Nominal Energy Capacity: 17.61 Wh
Nominal Charge Capacity: 4.85 Ah
Gravimetric Energy Density: 253 Wh/kg
Volumetric Energy Density: 718 Wh/L
Gravimetric Power Density: 507 W/kg
Volumetric Power Density: 1435 W/L
Max Continuous Charge: 4.85 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Coming soon to Simulate. Details available upon request.

Overview

Manufacturer: Samsung
Model: INR21700-50G
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2018

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 69.5 g
Volume: 24.53 cm³
Height: 70.15 mm
Diameter: 21.1 mm

Chemistry

Positive Electrode Material: Ni-based (high Ni)
Negative Electrode Material: Graphite/Si additive

Electrical

Nominal Energy Capacity: 17.61 Wh
Nominal Charge Capacity: 4.85 Ah
Gravimetric Energy Density: 253 Wh/kg
Volumetric Energy Density: 718 Wh/L
Gravimetric Power Density: 507 W/kg
Volumetric Power Density: 1435 W/L
Max Continuous Charge: 4.85 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Coming soon to Simulate. Details available upon request.

Max Continuous Charge (C-rate)

1 C

Max Continuous Discharge

9.7 A

Max Continuous Discharge (C-rate)

2 C

Voltage

Nominal Voltage

3.63 V

Max Voltage

4.2 V

Min Voltage

2.5 V

Max Continuous Charge (C-rate)

1 C

Max Continuous Discharge

9.7 A

Max Continuous Discharge (C-rate)

2 C

Voltage

Nominal Voltage

3.63 V

Max Voltage

4.2 V

Min Voltage

2.5 V
