E10

Inobat

Coming Soon

Coming soon to Simulate. Details available upon request.

Overview

Manufacturer: Inobat
Model: E10
Cell Type: Li-ion
Form Factor: Pouch
Country of Origin: Slovakia
Release Year: 2025

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

E10

Inobat

Coming Soon

Coming soon to Simulate. Details available upon request.

Overview

Manufacturer: Inobat
Model: E10
Cell Type: Li-ion
Form Factor: Pouch
Country of Origin: Slovakia
Release Year: 2025

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Minimum Discharge Temperature

-

Maximum Discharge Temperature

-

Mechanical

Mass: 113 g
Volume: 54.6 cm³
Length: 140 mm
Width: 60 mm
Thickness: 6.5 mm

Chemistry

Positive Electrode Material: Ni-based
Negative Electrode Material: -

Electrical

Nominal Energy Capacity: 36.1 Wh
Nominal Charge Capacity: 10.4 Ah
Gravimetric Energy Density: 319 Wh/kg
Volumetric Energy Density: 661 Wh/L
Gravimetric Power Density: 1597 W/kg
Volumetric Power Density: 3305 W/L
Max Continuous Charge: 41.6 A
Max Continuous Charge (C-rate): 4 C
Max Continuous Discharge: 52 A
Max Continuous Discharge (C-rate): 5 C
Nominal Voltage: 3.47 V
Max Voltage: 4.2 V
Min Voltage: 2.5 V

Minimum Discharge Temperature

-

Maximum Discharge Temperature

-

Mechanical

Mass: 113 g
Volume: 54.6 cm³
Length: 140 mm
Width: 60 mm
Thickness: 6.5 mm

Chemistry

Positive Electrode Material: Ni-based
Negative Electrode Material: -

Electrical

Nominal Energy Capacity: 36.1 Wh
Nominal Charge Capacity: 10.4 Ah
Gravimetric Energy Density: 319 Wh/kg
Volumetric Energy Density: 661 Wh/L
Gravimetric Power Density: 1597 W/kg
Volumetric Power Density: 3305 W/L
Max Continuous Charge: 41.6 A
Max Continuous Charge (C-rate): 4 C
Max Continuous Discharge: 52 A
Max Continuous Discharge (C-rate): 5 C
Nominal Voltage: 3.47 V
Max Voltage: 4.2 V
Min Voltage: 2.5 V
