SA88 | Voltt

SA88

Amprius

Premium Cell

We tear down cells and accurately measure every physical parameter

Book a Call

Overview

Manufacturer

Amprius

Cell Model

SA88

Cell Type

Li-ion

Form Factor

Pouch

Country of Origin

United States

Release Year

-

Thermal

Minimum Charge Temperature

-

Maximum Charge Temperature

-

Maximum Discharge Temperature

-

Minimum Discharge Temperature

-

Mechanical

Mass

98.5 g

Volume

42.67 cm³

Length

146 mm

Width

61.3 mm

Thickness

5.45 mm

Chemistry

Positive Electrode Material

Ni-based

Negative Electrode Material

Graphite/Si additive

Electrical

Energy

Volumetric Energy Density

849 Wh/L

Gravimetric Energy Density

368 Wh/kg

Nominal Energy Capacity

36.23 Wh

Nominal Charge Capacity

10.5 Ah

Power

Volumetric Power Density

8490 W/L

Gravimetric Power Density

3678 W/kg

Current

Max Continuous Charge

105 A

Max Continuous Charge (C-rate)

10 C

Max Continuous Discharge

105 A

Max Continuous Discharge (C-rate)

10 C

Voltage

Nominal Voltage

3.45 V

Max Voltage

4.2 V

Min Voltage

2.5 V

Fixed Rate

0.5 C1 C3 C

Load Type

Operation

Initial SOC [%]

Initial Cell Temperature [°C]

Heat Transfer Coefficient [W/m²K]

Want to edit the inputs and run your own Drive Cycles?
