M50LT

LG Chem

Ready to Simulate

M50LT

LG Chem

Ready to Simulate

Overview

Manufacturer: LG Chem
Model: INR21700-M50LT
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2020

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 67.5 g
Volume: 25.51 cm³
Height: 70.65 mm
Diameter: 21.44 mm

Chemistry

Positive Electrode Material: Ni-based (high Ni)
Negative Electrode Material: Graphite

Electrical

Nominal Energy Capacity: 18.2 Wh
Nominal Charge Capacity: 4.8 Ah
Gravimetric Energy Density: 270 Wh/kg
Volumetric Energy Density: 713 Wh/L
Gravimetric Power Density: 787 W/kg
Volumetric Power Density: 2083 W/L
Max Continuous Charge: 3.36 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

We tear down cells and accurately measure every physical parameter

Overview

Manufacturer: LG Chem
Model: INR21700-M50LT
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2020

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 67.5 g
Volume: 25.51 cm³
Height: 70.65 mm
Diameter: 21.44 mm

Chemistry

Positive Electrode Material: Ni-based (high Ni)
Negative Electrode Material: Graphite

Electrical

Nominal Energy Capacity: 18.2 Wh
Nominal Charge Capacity: 4.8 Ah
Gravimetric Energy Density: 270 Wh/kg
Volumetric Energy Density: 713 Wh/L
Gravimetric Power Density: 787 W/kg
Volumetric Power Density: 2083 W/L
Max Continuous Charge: 3.36 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

We tear down cells and accurately measure every physical parameter

Max Continuous Charge (C-rate)

0.7 C

Max Continuous Discharge

14.4 A

Max Continuous Discharge (C-rate)

3 C

Voltage

Nominal Voltage

3.69 V

Max Voltage

4.2 V

Min Voltage

2.5 V

Max Continuous Charge (C-rate)

0.7 C

Max Continuous Discharge

14.4 A

Max Continuous Discharge (C-rate)

3 C

Voltage

Nominal Voltage

3.69 V

Max Voltage

4.2 V

Min Voltage

2.5 V
