M50

LG Chem

Coming Soon

M50

LG Chem

Coming Soon

Overview

Manufacturer: LG Chem
Model: INR21700-M50
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2016

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 68 g
Volume: 24.53 cm³
Height: 70.15 mm
Diameter: 21.1 mm

Chemistry

Positive Electrode Material: Ni-based (high Ni)
Negative Electrode Material: Graphite/Si additive

Electrical

Nominal Energy Capacity: 17.6 Wh
Nominal Charge Capacity: 4.85 Ah
Gravimetric Energy Density: 259 Wh/kg
Volumetric Energy Density: 717 Wh/L
Gravimetric Power Density: 388 W/kg
Volumetric Power Density: 1077 W/L
Max Continuous Charge: 3.395 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Coming soon to Simulate. Details available upon request.

Overview

Manufacturer: LG Chem
Model: INR21700-M50
Cell Type: Li-ion
Form Factor: Cylindrical 21700
Country of Origin: South Korea
Release Year: 2016

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 68 g
Volume: 24.53 cm³
Height: 70.15 mm
Diameter: 21.1 mm

Chemistry

Positive Electrode Material: Ni-based (high Ni)
Negative Electrode Material: Graphite/Si additive

Electrical

Nominal Energy Capacity: 17.6 Wh
Nominal Charge Capacity: 4.85 Ah
Gravimetric Energy Density: 259 Wh/kg
Volumetric Energy Density: 717 Wh/L
Gravimetric Power Density: 388 W/kg
Volumetric Power Density: 1077 W/L
Max Continuous Charge: 3.395 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Coming soon to Simulate. Details available upon request.

Max Continuous Charge (C-rate)

0.7 C

Max Continuous Discharge

7.275 A

Max Continuous Discharge (C-rate)

1.5 C

Voltage

Nominal Voltage

3.63 V

Max Voltage

4.2 V

Min Voltage

2.5 V

Max Continuous Charge (C-rate)

0.7 C

Max Continuous Discharge

7.275 A

Max Continuous Discharge (C-rate)

1.5 C

Voltage

Nominal Voltage

3.63 V

Max Voltage

4.2 V

Min Voltage

2.5 V
