26V | Voltt

26V

EVE Energy

Coming Soon

We tear down cells and accurately measure every physical parameter

Book a Call

Overview

Manufacturer

EVE Energy

Cell Model

ICR18650-26V

Cell Type

Li-ion

Form Factor

Cylindrical 18650

Country of Origin

China

Release Year

2020

Thermal

Minimum Charge Temperature

-

Maximum Charge Temperature

-

Maximum Discharge Temperature

-

Minimum Discharge Temperature

-

Mechanical

Mass

48 g

Volume

17.54 cm³

Height

65.25 mm

Diameter

18.5 mm

Chemistry

Positive Electrode Material

LCO

Negative Electrode Material

Graphite

Electrical

Energy

Volumetric Energy Density

534 Wh/L

Gravimetric Energy Density

195 Wh/kg

Nominal Energy Capacity

9.36 Wh

Nominal Charge Capacity

2.6 Ah

Power

Volumetric Power Density

2668 W/L

Gravimetric Power Density

975 W/kg

Current

Max Continuous Charge

5.2 A

Max Continuous Charge (C-rate)

2 C

Max Continuous Discharge

13 A

Max Continuous Discharge (C-rate)

5 C

Voltage

Nominal Voltage

3.6 V

Max Voltage

4.2 V

Min Voltage

2.5 V

This cell is coming to Simulate soon - want to access cell insights now?

Speak with our team to access this advanced simulation output

Fixed Rate

0.5 C1 C3 C

Load Type

Operation

Initial SOC [%]

Initial Cell Temperature [°C]

Heat Transfer Coefficient [W/m²K]

Want to edit the inputs and run your own Drive Cycles?
