35V

EVE Energy

Coming Soon

35V

EVE Energy

Coming Soon

Overview

Manufacturer: EVE Energy
Model: 35V
Cell Type: Li-ion
Form Factor: Cylindrical 18650
Country of Origin: China
Release Year: 2022

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 50 g
Volume: 17.26 cm³
Height: 65.25 mm
Diameter: 18.45 mm

Chemistry

Positive Electrode Material: -
Negative Electrode Material: -

Electrical

Nominal Energy Capacity: 12.78 Wh
Nominal Charge Capacity: 3.5 Ah
Gravimetric Energy Density: 256 Wh/kg
Volumetric Energy Density: 740 Wh/L
Gravimetric Power Density: 745 W/kg
Volumetric Power Density: 2157 W/L
Max Continuous Charge: 1.5 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Coming soon to Simulate. Details available upon request.

Overview

Manufacturer: EVE Energy
Model: 35V
Cell Type: Li-ion
Form Factor: Cylindrical 18650
Country of Origin: China
Release Year: 2022

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 50 g
Volume: 17.26 cm³
Height: 65.25 mm
Diameter: 18.45 mm

Chemistry

Positive Electrode Material: -
Negative Electrode Material: -

Electrical

Nominal Energy Capacity: 12.78 Wh
Nominal Charge Capacity: 3.5 Ah
Gravimetric Energy Density: 256 Wh/kg
Volumetric Energy Density: 740 Wh/L
Gravimetric Power Density: 745 W/kg
Volumetric Power Density: 2157 W/L
Max Continuous Charge: 1.5 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Coming soon to Simulate. Details available upon request.

Max Continuous Charge (C-rate)

0.4 C

Max Continuous Discharge

10.2 A

Max Continuous Discharge (C-rate)

2.9 C

Voltage

Nominal Voltage

3.65 V

Max Voltage

4.2 V

Min Voltage

2.5 V

Max Continuous Charge (C-rate)

0.4 C

Max Continuous Discharge

10.2 A

Max Continuous Discharge (C-rate)

2.9 C

Voltage

Nominal Voltage

3.65 V

Max Voltage

4.2 V

Min Voltage

2.5 V
