FC4680

BYD

Premium Cell

FC4680

BYD

Premium Cell

Overview

Manufacturer: BYD
Model: FC4680
Cell Type: Li-ion
Form Factor: Cylindrical 4680
Country of Origin: China
Release Year: 2023

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 335 g
Volume: 137 cm³
Height: 80.5 mm
Diameter: 46.55 mm

Chemistry

Positive Electrode Material: LFP
Negative Electrode Material: Graphite

Electrical

Nominal Energy Capacity: 48 Wh
Nominal Charge Capacity: 15 Ah
Gravimetric Energy Density: 143 Wh/kg
Volumetric Energy Density: 350 Wh/L
Gravimetric Power Density: 146 W/kg
Volumetric Power Density: 357 W/L
Max Continuous Charge: 15.3 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Subscribe to Voltt Premium to run simulations using this cell

Overview

Manufacturer: BYD
Model: FC4680
Cell Type: Li-ion
Form Factor: Cylindrical 4680
Country of Origin: China
Release Year: 2023

Thermal

Minimum Charge Temperature: -
Maximum Charge Temperature: -
Minimum Discharge Temperature: -
Maximum Discharge Temperature: -

Mechanical

Mass: 335 g
Volume: 137 cm³
Height: 80.5 mm
Diameter: 46.55 mm

Chemistry

Positive Electrode Material: LFP
Negative Electrode Material: Graphite

Electrical

Nominal Energy Capacity: 48 Wh
Nominal Charge Capacity: 15 Ah
Gravimetric Energy Density: 143 Wh/kg
Volumetric Energy Density: 350 Wh/L
Gravimetric Power Density: 146 W/kg
Volumetric Power Density: 357 W/L
Max Continuous Charge: 15.3 A

Simulate This Cell

Run simulations with custom duty cycles and pack configurations

Subscribe to Voltt Premium to run simulations using this cell

Max Continuous Charge (C-rate)

1 C

Max Continuous Discharge

15.3 A

Max Continuous Discharge (C-rate)

1 C

Voltage

Nominal Voltage

3.2 V

Max Voltage

3.65 V

Min Voltage

2 V

Max Continuous Charge (C-rate)

1 C

Max Continuous Discharge

15.3 A

Max Continuous Discharge (C-rate)

1 C

Voltage

Nominal Voltage

3.2 V

Max Voltage

3.65 V

Min Voltage

2 V
